PAC H64 JD 275HP T4F
The PAC H64 JD 275HP T4F for high-pressure applications, have been designed to reduce downtime and prolong lifespan, saving operational costs.
This centrifugal pump can handle liquids containing solids of up to 3" in size. This makes it particularly well suited to industrial applications, such as water transfer in the oil and gas sector, quarrying and surface mining, construction, and municipal applications.
Even with suction heights of several feet the machine rapidly evacuates the air from the suction pipe and starts to pump. Additionally, thanks to the enclosed impeller, the PAC range is also suitable for pumping liquids with solids in suspension with best possible efficiency.
SPECS
Performance Curves
| Pump | |
|---|---|
| Model | PAC H64 |
| Qmax | 1,950 USgpm |
| Hmax | 500 ft |
| Q max eff. | 2,340 USgpm |
| Eff. max | 69 % |
| Suction port | 6" Flange - ANSI class 150 |
| Delivery port | 4" Flange - ANSI class 150 |
| Impeller type | Enclosed, 2 vane |
| Impeller diameter | 17" |
| Solids handling | 3" |
| Material | |
| Casing | ASTM A536 ductile iron |
| Impeller | ASTM A743 CA6NM |
| Wear ring | ASTM A48 Class 20 grey iron |
| Wear plate | ASTM A48 Class 20 Grey Iron + NBR rubber coating |
| Shaft | AISI 630 stainless steel |
| Mechanical Seal faces | Silicon carbide Vs Silicon carbide |
| Elastomers | VITON |
| Check Valve | ASTM A536 ductile iron + NBR rubber flap |
| Separator | Steel |
| Priming System | |
| Vacuum pump | |
| Vacuum pump type | Diaphragm |
| Nominal air capacity | 50.0 cfm |
| Max vacuum | - 26.6 inHg |
| Drives | Link belt |
| Engine | |
|---|---|
| Make | John Deere |
| Model | 6068HFC08 |
| Type | Diesel turbo common rail |
| Displacement | 549 inĀ³ |
| No. cylinders | 6 |
| Cooling | Liquid with radiator |
| Rpm type | Variable |
| Max operating speed | 2100 rpm |
| US emissions | EPA Tier 4F |
| Starting | Electric |
| Engine system voltage | 24 V |
| Engine Power rating | 275 HP |
| Control panel | |
| Model | PW 750 |
| Manual operation | |
| Automatic operation: start-stop with transducers or floats | |
| FleetLink Optional | |
| Arrangement | |
| Technical data | |
| Material | ASTM A36 steel |
| Coatings | Epoxy powder, average thickness of 3 MIL |
| Features | Lifting beam. Fork lift pockets. Pump access through hinged door. Protected PE fuel tank |
| Battery | Acid charge Pb-Ca maintenance free, 24V - 1100 CCA |
| Fuel tank capacity | 173 USG |
| DEF tank capacity | 46.7 USG |
| Fuel consumption | 9.7 US Gal/hr @2,100rpm |
| Dry weight | 8,770 lbs |
| Wet weight | 10,300 lbs |
